Rick’s Motorsport Electrics Honda CB750 / 900 (Early 80’s) Lithium Ion Battery Compatible Regulator Rectifier 14_103

$170.00 AUD

or 4 fortnightly payments of $42.50 with Afterpay $200 Min Spend. AU Customers Only. More info

Rick’s Motorsport Electrics Aftermarket Lithium Ion Compatible Rectifier-Regulator is designed with a lower voltage set point to work with lithium ion batteries. Rick’s part # 14-103 is a plug n play piece for Vintage Honda Street Bikes with the following OE #’s: 31600-MA6-910, 316-MA6-000, 311600-MA7-008, 31600-425-008, 31600-461-771 or 311600-MG5-000. **This rec-reg is not for use with standard lead acid batteries. The voltage set point is 14V +/- .2. Please contact the manufacturer of your Lithium Ion Battery to ensure our product has the correct set point for their product.

***Rick’s Motorsport Electrics One Year Product Warranty is for the Rec-Reg only. Rick’s warranty does not cover batteries of any type.

In stock (can be backordered)

- +
SKU: RICKS-14_103 Categories: ,

Compatible with the following:

What comes in the box?

1 x Lithium Ion Battery Compatible Regulator Rectifier 14_103



Product Fitment

This part fits the following vehicles:

Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1980 Honda Street Bike CB750C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1981 Honda Street Bike CB750C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1982 Honda Street Bike CB750C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1979 Honda Street Bike CB750F Supersport
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1980 Honda Street Bike CB750F Supersport
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1981 Honda Street Bike CB750F Supersport
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1982 Honda Street Bike CB750F Supersport
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1979 Honda Street Bike CB750K
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1980 Honda Street Bike CB750K
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1981 Honda Street Bike CB750K
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1982 Honda Street Bike CB750K
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1979 Honda Street Bike CB750L Limited
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1982 Honda Street Bike CB750SC Nighthawk
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1983 Honda Street Bike CB750SC Nighthawk
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1980 Honda Street Bike CB900C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1981 Honda Street Bike CB900C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1982 Honda Street Bike CB900C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1981 Honda Street Bike CB900F Supersport
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1982 Honda Street Bike CB900F Supersport
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1983 Honda Street Bike CB1000C Custom
Lithium Ion Battery Compatible Rectifier Regulator 14_103 for a 1983 Honda Street Bike CB1100F Super Sport

Disclaimer

Modifying vehicles is a specialist task and requires the knowledge and experience of competent individuals to be conducted safely, particularly where vehicle performance may change from the original specification. There is an element of risk associated with any modification and it is up to you to ensure these risks are minimised and taken into account. Further, some components may not be suitable for installation as a result rules and regulations. It is your responsibility to ensure that all legal requirements are met, relevant to your country and/or jurisdiction. JAX Garage takes no responsibility for any damage or injury as a result of any component or vehicle modification.

Additional information

Weight 0.20 kg
Dimensions 10 × 10 × 8 cm
Brand

Ricks Electrics
Fitment

Honda CB750 F, Honda CB750 K
