mo.view” version
Allows mounting of all mo.view handlebar end mirrors without moving the grips or fittings on the handlebar. It creates a clamping surface for the handlebar end mirror outside the steering tube.
It is CNC machined from billet aluminum and anodized black. The screwable lid is concave in design and decorated with a crown on the outside. The clamping in the end of the handlebar is done by tightening a M6 screw under the lid, which expands the clamping pieces and allows a stable mounting.
The bar adapter uni cap comes with two clamps for the left and right side of the handlebar. It is mounted directly in the end of the handlebar (22 mm, 7/8 and 1 inch) with a free inside diameter (without internal thread) from 12 to 21 mm.
mo.view and mo.blaze” version
Allows mounting of all mo.view handlebar end mirrors in combination with the mo.blaze handlebar end indicators without moving the grips or fittings on the handlebar. It creates a clamping surface for the handlebar end mirror outside the steering tube and at the same time allows the mounting of the handlebar end turn signal.
It is CNC machined from billet aluminum and anodized black. The clamping in the end of the handlebar is done by tightening a M6 screw inside the adapter, which expands the clamping pieces and allows a stable mounting.
Then tighten the mirror clamp on the adapter and thus simultaneously clamped the handlebar end indicators. The bar adapter uni disc/cone is supplied with two clamps for the left and right side of the handlebar. It is mounted directly in the end of the handlebar (22 mm, 7/8 and 1 inch) with a free inner diameter of 12 to 21 mm (without internal thread) and a length of 90 mm.
